Injectable Tags

Animal Tags are passive tags operated for identification of livestock, health record keeping, insurance and slaughter houses. They are thrusted through injectable applicator. They provide adequate reading range to detect livestock from a considerable distance. Printing and encoding of these tags are also available for easy implementation



Description:

• The injectable tags usually contain RFID microchips. These microchips can store and transmit information wirelessly when scanned by an RFID reader.
• Injectable RFID tags are commonly used in the identification and tracking of animals. This is especially common in pets and livestock.



Specification	Details
Dimensions	2*12mm / 4*34mm / 4*22mm / 3*14mm
Weight	± 2gm
Encasement / Material	Bio glass
Packaging	Sterilised Premium Plastic Packing
Protocol	ISO 11784, ISO 11785 (FDX-B)
Operating Frequency	134.2 KHz
Read Range Fixed Reader	Up to 30m (Reader Dependent)
Read Range Handheld Reader	Up to 10m (Reader Dependent)
IC Type	EM4305
EPC Memory	Chip Dependent
User Memory	Chip Dependent
Operating Temperature	-25°C to +85°C
Storage Temperature	-40°C to +85°C
IP Rating	IP68
Chemical Resistance	Alcohol, Ammonium Chloride 25%, Fuel B, HCL 10%, Salt Water
Shock & Vibration	IEC 68.2.29 [40 g, 18 ms, 6 axis, 2000 times] | IEC 68.2.6 [10 g, 10 to 2000 Hz, 3 axis, 2.5 h]
Tagging Method	Subcutaneous / External Housing
